应用领域与百科/Brief Introduction：

全自功注塞泵式膏体酱分安装系统是属于我平台认知市面供需规划设计的新商品。机用户用SUS304不锈钢圆管注塞泵式量值溯源泵来执行分装，且集自功上盖、自功旋盖、汽车电器不间断为分立式，金钱实用性强，土地征用面積小，比较广泛应运于医药化工公司、面制品、农药杀菌剂、化工公司、画妆品等产业的固体包装袋，不符合GMP标准化特殊要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

的特点/characteristic：

◆主要包括轴向柱塞泵式的计量泵执行命令装灌，常用各式乳白色度液體，精密度较高；泵的设备构造主要包括快接式拆迁系统，以及洗涤、清洁消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式计量检测泵活塞杆环材質表明该行业及液滴基本成分的多种利用硅生橡胶，四氟氯乙烯或的材質，专项 领域利用工业陶瓷材質。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调控程序，直流变频变速，一键化因素高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不分装，自然计数器技能。Lack of bottle filling, automatic counting function◆装量的更改便宜，可以次的更改完全的记量泵的充填量，也可对於其它的记量泵通过微幅的更改；操控方便，的更改高速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆罐装设备针头存在防渗漏平衡装置，充填时潜泳到瓶底罐装设备，迟滞升，避免 汽泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆主机可适用人群各个要求的玻璃瓶，懂得调整简易，可在间歇间内提交。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆服务器按GMP耍求的设计。The machine designed according to the requirements of GMP

技木性能参数/technic parameter：

适于水瓶座尺寸Size of bottles	20-1000ml（♈结合符合要求为您加工定制）20-1000 - ml (according to your need）
使用矿泉水瓶孔径Apply the bottle diameter	¢20-¢150mm
可用盖子样式Apply the lid specifications	¢20-¢70mm
生產实力 production capacity	四头灌装线：1000-2500瓶/个钟头 Four filling head: 1000-2500 bottles per hour 八头灌装设备：2500-4000瓶/小的时候 Eight head filling: 2500-4000 bottles per hour 12头包装：4000-6000瓶/小时内 12 head filling: 4000-6000 bottles per hour
装量误差率The load error	±1%
旋盖合格证书率Screw cover percent of pass	≥99%
电源开关power supply	380V，50HZ
耗油率power	3.0KW
气动阀门gas sources	0.4-0.75MPA
运行速度把控好speed control	直流变频调速器variable speed
