使用用途与简绍/Brief Introduction：

什么是服务器所选取特异三通管包装阀，适于于水剂和膏霜类企业产品的包装，尤其是对高107硅橡胶凝固点物品（如浓酱、尖椒酱、番茄酱、种衣剂、微乳剂、浮窗剂等）的感觉对比显眼，且精确高。什么是服务器所选取PLC可编写程序控住，搭配64英寸触摸式屏电脑网页控制系统，进行 自動进瓶，自動包装，自動出瓶，电器机 ，自动元元件均所选取国际级公司，保障安全生产了卓越的高质量和耐久固定的性。本机 组成简简单单，实际操作利于，是国内外非常理想的采取高107硅橡胶凝固点物品的包装机 。什么是服务器装备了解决办法漏滴与金属拔丝的包装闷头，保障安全生产包装结束后无漏滴，无金属拔丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

结构特征/Characteristic：

◆设定机体系——采取三菱数控体系PLC设定机体系，分装含量任意上下调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆进行作业网页——6屏幕尺寸彩屏手触式进行作业网页，最直观很简单、平安安全Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆效果改进方案——开料有防渗漏装备，可据物料管理性能特点应具下潜装罐效果。（此效果应该选择使用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器开关电子器件——均按照世界著时尚加盟品牌牌加盟品牌，狠抓设配的安全防护可靠的、更准确性好；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械化零配件——系统零配件均用更优质304不锈不锈钢材料钢板网作,假如必须要遇到货品能用316L另收费用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆筛选器检验——实时交通筛选器，对工作上销售量形象表现。Counting test, real-time, intuitive reflect the yield of work.◆装灌加测——无瓶不灌、瓶数不太不灌Bottle filling test - no bottle no filling, not enough◆维保时候——滤油机合适GMP让，可轻易拆开、的清洗维保。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆对调品种——撤换装罐品种时，只需要简单设定，快速拿下。Changing specifications - change the filling specifications, simply adjust, easy fix.◆健康配资——配资了健康结构，使仪器的方法区域更干净卫生情况。（此健康配资不错标准配置）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

水平参数指标/technical parameters：

灌装生产线头数The number of filling head	8头（待选4、6、8、10、14个包装头）ꦫ8 head (optional 4, 6, 8, 10, 12 filling head)
适合瓶径 Applicable bottles Drive	Ф33-Ф100 mm
检定要求measure precision	±1%
罐装余量Canned capacity	150-1000ml
生產力量Production Capacity	2400-4000瓶/每小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
